| Model | N2 GAS PURITY [%] AND VOLUME [Nm3/hr] | ||||
|---|---|---|---|---|---|
| 99 | 98 | 97 | 96 | 95 | |
| NM-B01 | 0.071 | 0.10 | 0.14 | 0.17 | 0.19 |
| NM-B02 | 0.15 | 0.21 | 0.27 | 0.33 | 0.40 |
| NM-B05 |
0.36 | 0.51 | 0.65 | 0.78 | 0.92 |
| NM-B05F |
0.66 | 0.84 | 1.1 | 1.4 | 1.60 |
| NM-0804NF |
1.3 | 1.7 | 2.3 | 2.7 | 3.3 |
| NM-C07F |
1.6 | 2.4 | 3.1 | 3.8 | 4.5 |
| NM-C10F |
2.4 | 3.7 | 4.7 | 5.8 | 6.9 |
| NM-510F |
12 | 17 | 22 | 27 | 32 |
| NM-710F | 21. | 0 31 | 41 | 51 | 62 |
| NM-810FC | 22. |
0 34 | 45 | 55 | 67 |
| Model | External dimensions [mm] | Connection (Rc) | Weight [kg] | ||||
|---|---|---|---|---|---|---|---|
| L | D | d | INLET | OUTLET | Permeate | ||
| NM-B01 | 235 | 54 | 50 | 3/8 B |
3/8 B |
∮20 |
0.6 |
| NM-B02 | 360 | 54 | 50 | 3/8 B |
3/8 B |
∮20 |
0.9 |
| NM-B05 |
61 | 54 | 50 | 3/8 B |
3/8 B |
∮20 |
1.4 |
| NM-B05F |
61 | 54 | 50 | 3/8 B |
3/8 B |
∮20 |
1.4 |
| NM-0804NF |
490 | 85 | 80 | 3/8 B |
3/8 B |
∮20 |
2.7 |
| NM-C07F |
800 | 109 | 70 | 3/8 B |
3/8 B |
1/2 B |
4.2 |
| NM-C10F |
1110 | 109 | 70 | 3/8 B |
3/8 B |
1/2 B |
5.0 |
| NM-510F |
1080 | 180 | 130 | 1 B |
1 B |
1 1/2 B |
16.0 |
| NM-710F | 1080 | 244 | 180 | 1 1/2B |
1 1/2B |
2 B |
33.0 |
| NM-810FC | 1026 |
249 | 200 | - | - | - | 22.5 |
